5.5inch Portable 4+64G Handhelds PDA Mobile Computer Windows PDA Data Collector Q501

Overview

Basic Info.

Model NO.	Q501
Scanner Window	Tempered Glass
GPS	Build in GPS, Support a-GPS
Camera	5m Piexl Rear Camera, Supprot 1d & 2D Scan
Wireless Wan	2g, 3G, 4G, Bluetooth 4.1+Le
Touch Panel	Corning Gorilla Glass, Multi-Touch Panel
Screen Size	5.5-Inch
Battery	5000mAh/3.7V
Product	Android PDA Scanner
Transport Package	Carton Box
Specification	181*88*20mm
Trademark	OEM/ODM
Origin	China
HS Code	8470501000
Production Capacity	30000/Month

Product Description

Product Description

Q501Cost-effective Windows 10 mini PDA scanner

The Q501 is a powerful and durable mobile device that fits in the palm of your hand. It has endless applications in industries such as logistics, warehouse management, retail, and healthcare. The optional built-in 1D/2D barcode scanner can be used to track inventory, for Barcode Medication Administration, positive patient ID, and point-of-sale applications.-Windows 10 OS - Embedded Professional Laser Barcode Scanner- NFC and QR Code Scanner optional- 4+64 GB memory- 5.5-inch Industrial capacitive screen - Long battery working time >8 hours- GPS/AGPS supported- 5MP auto focus camera with LED flash- Compact & lightweight design for easy portability

Product Parameters

Operation System
OS	Windows 10 home/pro/iot
CPU	intel cherry trail Z8350
Memory	4 GB RAM / 64 GB Flash
Languages support	English, Simplified Chinese, Traditional Chinese, Japanese,Spanish, German, French, Italian, Portuguese, Korean and multiple languages
Hardware specification
Screen Size	5.5 inch color 1920 x 1080 display ,500 nits
Touch Panel	Gorilla glass III with 5 points Capacitive Touch Screen
Buttons / Keypad	V+ -, Power, F1, F2, F3,F4,SCAN-KEY
Card readers (optional)	Contactless Card , Support ISO / IEC 14443 A&B,Mifare, felica card conform to EMV / PBOC PAYPASS standard
Camera	Rear 5 megapixels, with flash and auto focus function
Indicator Type	LED, Speaker, Vibrator
Battery	Removable rechargeable li-ion polymer, 5000mAh
Symbologies
1D Barcode	1D : UPC/EAN/JAN, GS1 DataBar, Code 39, Code 128, Code 32, Code 93, Codabar/NW7, Interleaved 2 of 5, Matrix 2 of 5, MSI, Trioptic
2D Barcode	2D :PDF417, MicroPDF417, Composite, RSS TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, U PostNet, US Planet, UK Postal, Australia Postal, Japan Postal, Dutch Postal. etc
Communication
Bluetooth®	Bluetooth®4.2
WLAN	Wi-Fi 802.11a/b/g/n/r/ac(2.4G+5G dual-band Wi-Fi), fast roaming,5G PA
WWAN	2G:B2/B3/B5/B8 3G:WCDMA:B1/B5/B8,CDMA BC0,TD-SCDMA:B34/B39 4G:FDD-LTE:B1/B3/B5/B7/B8/B20,TDD-LTE:B34/B38/B39/B40/B41
GPS	GPS/BDS/Glonass, error range ± 5m
I/O Interfaces
USB	Micro USB*1 OTG , 1*USB 3.0
POGO PIN	8 pin back, included(2USB, 1 RS232, 1 UART, 3.3V, 5V out put), 5V input 8pin on bottom:(1*USB) 5V input
SIM Slot	Single SIM card
Expansion Slot	Micro SD, up to 128 GB
Audio	One speaker with Smart PA (95±3dB @ 10cm), One receiver, Dual noise-cancelling microphones
Enclosure
Dimensions ( W x H x D )	181*88*20mm
Weight	500g (with battery)
Durability
Drop Specification	1.2m, 1.5m with boot case ,MIL-STD 810G
Sealing	IP65
Environmental
Operating temperature	-20°C to 50°C
Storage temperature	- 20°C to 70°C (without battery)
Charging temperature	0°C to 45°C
Relative Humidity	5% ~ 95% (Non-Condensing)
What comes in the box
The standard package contents	Q501 Device USB Cable Adaptor (Europe)
Optional Accessory	Hand StrapCharging dockingVehicle cradleCar holder

Certifications

Company Profile

Professional ODM industrial terminal designer and manufacturer

Shenzhen Hosoton Technology Co., Ltd. is a experienced player in R&D, manufacturing and marketing digital smart industrial equipment, such as Tablet PC, pipe endoscope camera, handheld PDA scanner and any other ODM industrial devices. Our products are widely applied to logistics, store management, municipal construction, finance etc.

FAQ1.How to order?We will quote the price to customers after received their requests. After customers confirmed the specification, they will order samples for testing. After inspected all devices , it will be sent to the customer by air.
2.Do you have any MOQ (minimum order)?We don't have any MOQ and 1pcs sample order will be supported .
3.What is the payment terms?T/T bank transfer is accepted ,and 100% balance payment before goods shippment
4.What is your OEM requirement?You can choose multiple OEM services includes boot animation, color box design, change model name, logo label design and so on , and some of these services can be done for 1 qty.
5.How many years have you been established?We focus on the rugged mobile device industry over 9 years.
6.How long is the warranty?We offer 1 year warranty to all of our products, and we also provide extended warranty based on your requirements .
7.How long is the delivery time?Normally the sample devices could be delivered within 5 working day , and the bulk order will depend on the quantity .If you need a drop- shipping service, we are experienced and can ship directly from China to your customers.
8.What are the accessories?The default accessories of our rugged devices are chargers and USB cables. There are multiple optional accessories are available, such as vehicle mount, docking station, wireless mat, hand strap, and so on. Welcome to visit our product pages for more details!
9.How to repair the devices if any issues?We will offer online technical support for product issues. If the issues is non-human factor, we will send components and parts to customers to repair.
10.How to install multiple functions into 1 device?You can ask us to install the 2D scanner, RFID, and high accuracy GPS module into the rugged device before shippment ,also we could provide ODM service for some specific function.
11.What kind of software support I can get?Hosoton provided lots of tailor-made rugged solutions to customers, and we can also provide SDK, software online upgrade , etc.
12.What kind of services can you provide?

There is two services models for your option ,One is OEM service ,which is with customer's brand based on our off-the-shelf products ,the other is ODM service according to the individual demands ,which included Appearance design ,structure design ,Mold development ,software and hardware development etc.
